z386 is an open-source FPGA implementation of the Intel 80386 CPU built around original microcode. It can run DOS, protected-mode programs, and classic games, offering insights into historic microarchitecture. Its development marks a significant step in hardware reconstruction and education.
The z386 project is an open-source FPGA implementation of the Intel 80386 CPU, built around the original microcode, capable of running DOS 6, DOS 7, and protected-mode applications like Doom.
The project, led by an enthusiast known as reenigne, has reconstructed the 386 microarchitecture to the point where it can boot and run real software, including classic games and protected-mode programs. It uses a microcode ROM with 2,560 entries, matching the original design, and performs at speeds comparable to a 70MHz 386 or low-end 486.
The FPGA implementation includes key 386 units such as prefetch, decode, microcode sequencer, ALU, segmentation, protection, paging, and memory interface, mirroring the original architecture while incorporating FPGA-friendly optimizations. It is capable of running DOS and protected mode applications like DOS/4GW and DOS/32A, with benchmarks showing performance close to historical hardware.
Why It Matters
This project offers a rare, open-source reconstruction of the 386 microarchitecture, providing educational insights into microcode-driven CPU design and the evolution of x86 architecture. It also enables enthusiasts and researchers to study and experiment with authentic hardware behavior without proprietary restrictions, fostering deeper understanding of legacy systems.
